In the realm of utility-scale renewable energy, 5MWh battery compartments have emerged as a cornerstone for utility battery storage and utility scale batteries, delivering robust energy solutions for grid stability, renewable integration, and industrial applications. Yijia Solar’s 5MWh systems combine high-capacity storage with climate-adaptive design, ensuring reliable performance for utilities, solar farms, and remote microgrids worldwide.
High-Capacity System Architecture
Each 5MWh battery compartment is engineered with 12 battery clusters, each housing 4 liquid-cooled PACKs in a 1P104S configuration, achieving:
- Total Energy Storage: 5015.9616kWh at 25°C (0.5C rating)
- Nominal Voltage: 1331.2V (working range: 1164.8–1497.6V)
- Sustainable Power: 2507kW (charge/discharge)
- DC Efficiency: ≥93% under standard conditions
The system utilizes 314Ah lithium iron phosphate (LFP) cells, renowned for their longevity (6,000+ cycles) and safety, operating reliably from -20°C to +60°C (discharge) .
Advanced Thermal Management
A 60kW liquid cooling system maintains cell temperatures within ±2°C, featuring:
- Refrigerant: R410A
- Coolant: 50% ethylene glycol solution
- Flow Rate: 500L/min
- Noise Level: <85dB
This ensures optimal performance in extreme climates, from desert heat to alpine cold .
Intelligent BMS for Grid Stability
Yijia Solar’s three-tier BMS delivers:
- SOC Accuracy: <8%
- Temperature Precision: ±2°C
- Real-time Cell Monitoring: Over 4,000 cells per compartment
- Grid-compliant Protection: Overvoltage, overcurrent, and thermal runaway mitigation
Grid Stabilization for Solar Farms
A 15MWh system (3×5MWh compartments) in a desert solar project:
- Smoothed daily power fluctuations for a 10MW solar farm
- Reduced diesel generator usage by 90%
- Withstood 50°C heat and sandstorms via IP54-rated enclosures
Industrial Microgrid Resilience
A manufacturing plant deployed a 10MWh system to:
- Provide 8 hours of backup power during grid outages
- Achieve THD <3% for sensitive equipment
- Cut CO₂ emissions by 6,000 tons/year
Remote Utility Electrification
In a rural microgrid project, a 5MWh compartment:
- Powered 2,000 households with 24/7 energy
- Scaled to 15MWh over two years to meet demand growth
- Enabled water pumping and healthcare facilities
Scalability & Modularity
- Start with 5MWh and expand to 100+MWh via parallel containers
- 20-foot standard dimensions (6058×2438×2896mm) optimize transport and installation
Climate Adaptability
- Desert: Anti-dust coatings and sealed cooling loops
- Coastal: C3 anti-corrosion coatings and salt-air filtration
- High-Altitude: -20°C operation and 5,400Pa snow load resistance
Safety & Compliance
- Dual-layer fire suppression with 52kg perfluorohexanone
- Compliant with GB/T 36276-2018, IEC 62133, and T/CEC 373-2020
- 25-year panel warranty, 10-year battery warranty
End-to-End Solutions
- Free Site Assessment: 3D modeling for optimal system design
- Localized Engineering: Tailored to regional climate challenges
- Global Case Library: Explore [utility projects] in similar environments
Technical Excellence
- ISO-certified manufacturing (IP54, GB 50217-2018)
- Grid-code compliant inverters (10kV integration)
- Remote monitoring via Modbus/IEC 61850 protocols
Ready to Explore Utility Battery Solutions?
1. Download Specs: Visit [Yijia Solar’s website]for 5MWh datasheets
2. Request a Quote: Get a custom proposal based on your grid needs
3. Consult Experts: Schedule a call to discuss utility-scale integration
Invest in reliable, scalable utility battery storage—contact Yijia Solar today to power your next large-scale energy project.
