In the rapidly evolving landscape of renewable energy, 5MWh battery compartments stand as a cornerstone for large scale battery energy storage systems, delivering unmatched reliability and scalability for solar power projects. Designed to meet the rigorous demands of utilities, industries, and remote communities, these modular battery storage systems from Yijia Solar combine technical excellence with climate-adaptive design, ensuring optimal performance in diverse environments.
High-Capacity Energy Storage Architecture
Each 5MWh battery compartment integrates 12 battery clusters, each housing 4 liquid-cooled PACKs in a 1P104S configuration, achieving:
- Total Energy Storage: 5015.9616kWh at 25°C (0.5C rated discharge)
- Nominal Voltage: 1331.2V with a working range of 1164.8–1497.6V
- Sustainable Power: 2507kW (both charge and discharge)
- DC-Side Efficiency: ≥93% under nominal conditions
The system utilizes 314Ah lithium iron phosphate (LFP) cells, each with a nominal voltage of 3.2V and a working range of 2.8–3.6V. These cells demonstrate exceptional thermal stability, operating reliably at -20°C to +60°C (discharge) and 0°C to +60°C (charge) .
Advanced Thermal Management System
Equipped with a 60kW liquid cooling unit, the compartment maintains cell temperatures within ±2°C via:
- Refrigerant: R410A
- Coolant: 50% ethylene glycol aqueous solution
- Circulation Flow: 500L/min
- Noise Level: <85dB
- Dimensions: 1200×440×2400mm
This system ensures consistent performance in extreme climates, from -30°C mountain regions to +50°C desert zones .
Intelligent Battery Management System (BMS)
Yijia Solar’s three-tier BMS delivers:
- SOC Estimation Accuracy: <8%
- Temperature Measurement Precision: ±2°C
- Cell Voltage Monitoring: ±0.3% accuracy
- Protection Functions: Overvoltage, overcurrent, thermal runaway, and insulation fault detection
- Communication Interfaces: CAN/RS485/Ethernet with Modbus protocol support
The BMS monitors over 4,000 cells per compartment, enabling real-time health assessment and predictive maintenance .
Battery Pack Parameters
Each HV332.8/314 pack features:
- Nominal Voltage: 332.8V
- Capacity: 314Ah
- Energy: 104.4992kWh
- Charge/Discharge Rate: 0.5C continuous
- Dimensions: 783×2180×246mm
- Operating Temperature: -20°C to +60°C (discharge)
The dual-cluster high-voltage box includes:
- Circuit Breakers: 250A/DC1500V
- DC Contactors: 350A/DC1500V
- Pre-Charge Resistor: 200W/50Ω
- Fuses: 350A/DC1500V
- Max. System Voltage: 1500V
- Max. Current: 250A
Container Engineering
- Dimensions: 6058×2438×2896mm (20-foot standard)
- Weight: ~45 tons
- Protection Grade: IP54 (dust/water ingress resistance)
- Corrosion Rating: C3 (suitable for coastal/saline environments)
- Thermal Insulation: Heat transfer coefficient ≤1.5W/(m²·°C)
- Seismic Resistance: Designed for ≥6.5 magnitude earthquakes
- Temperature Tolerance: Operates from -30°C to +50°C without performance derating
- Dust & Sand Protection: Sealed liquid cooling loops and anti-static panel coatings
- Snow & Wind Resistance: 5,400Pa snow load and 2,400Pa wind resistance
- Salt Mist Resistance: Marine-grade aluminum frames and anti-corrosion coatings
These specifications are validated in Yijia Solar’s case studies, including a 15MWh desert installation that maintained 95% efficiency through 50°C heat and sandstorms .
- Warranty Coverage: 25-year panel warranty, 10-year battery warranty, 5-year BMS warranty
- Certifications: Compliant with GB/T 36276-2018, IEC 62133, T/CEC 373-2020 (fire safety), and ISO 9001
- Scalability: Modular design allows seamless expansion from 5MWh to 100+MWh
- Global Support: 24/7 technical service with regional installation teams
Ready to Explore Technical Details?
For detailed datasheets or custom system design based on your project requirements:
1. Visit Yijia Solar’s Website: [https://www.yijiasolar.com] to download product specs
2. Request a Technical Consultation: Connect with our engineers for site-specific solutions
3. View Case Studies: Explore [real-world applications]of 5MWh compartments in diverse climates
Invest in reliability and performance—contact us today to discuss how 5MWh battery storage can transform your energy project.
